CK5112 CNC Vertical Lathe Machine Cnc Vertical Borer Milling And Drilling
CK5112 CNC Vertical Lathe Machine Cnc Vertical Borer Milling And Drilling
CK5112 CNC Vertical Lathe Machine Cnc Vertical Borer Milling And Drilling
CK5112 CNC Vertical Lathe Machine Cnc Vertical Borer Milling And Drilling
CK5112 CNC Vertical Lathe Machine Cnc Vertical Borer Milling And Drilling
CK5112 CNC Vertical Lathe Machine Cnc Vertical Borer Milling And Drilling
CK5112 CNC Vertical Lathe Machine Cnc Vertical Borer Milling And Drilling
CK5112 CNC Vertical Lathe Machine Cnc Vertical Borer Milling And Drilling

CK5112 CNC Vertical Lathe Machine Cnc Vertical Borer Milling And Drilling

Product Details

Place of Origin: Henan, China

Brand Name: BAISHUN MACHINERY

Certification: CE，ISO

Model Number: CK5112

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 Set

Price: Negotiable

Packaging Details: Export standard wooden case package or Negotiation with customers

Delivery Time: 30-35 work days

Payment Terms: L/C, T/T, Western Union

Supply Ability: 20 Set/Sets per Month

Get Best Price

Product Details

Product Description
Highlight:

CK5112 CNC Vertical Lathe Machine

,

CNC Vertical Lathe Machine Milling

,

cnc vertical lathe

Max. Length Of Workpiece (mm):
1200
Max. Spindle Speed (r.p.m):
180 R.p.m
Spindle Bore(mm):
105
No. Of Spindles:
Single
Travel (X Axis)(mm):
700 Mm
Positioning Accuracy (mm):
±0.005
CNC Control System:
GSK
Product Name:
CK5112 Vertical Lathe
Max. Length Of Workpiece (mm):
1200
Max. Spindle Speed (r.p.m):
180 R.p.m
Spindle Bore(mm):
105
No. Of Spindles:
Single
Travel (X Axis)(mm):
700 Mm
Positioning Accuracy (mm):
±0.005
CNC Control System:
GSK
Product Name:
CK5112 Vertical Lathe
CK5112 CNC Vertical Lathe Machine Cnc Vertical Borer Milling And Drilling
Product Description

CNC controlling Automatic Vertical Turning Lathe

Product Description

The CNC vertical lathe, also known as a vertical turning center, is a machine tool used for turning and cutting metal components with high precision and efficiency.

CNC vertical lathe has a vertical spindle that holds and rotates the work piece. They are widely used in the manufacturing industry for producing large and heavy components, such as gears, turbines, and aerospace parts. They are particularly useful for turning components with a high aspect ratio.

Additionally, CNC vertical lathes are highly automated and can be programmed to perform a wide range of machining operations, such as turning, drilling, boring, threading, and milling, with minimal human intervention.

Overall, The CNC vertical lathes are a versatile and efficient machining tool that offer high precision and automation capabilities, and that is why makes them an essential component of modern manufacturing processes.

The CNC Vertical lathe is a big machine used for handling large and heavy workpieces with a wide radial size and relatively smaller axial size. It's designed to process workpieces with complex shapes, such as cylindrical surfaces, end surfaces, conical surfaces, cylindrical holes, conical holes, and more. Additionally, with the help of additional tools, it can also perform operations like thread cutting, turning spherical surfaces, imitation machining, and grinding. Unlike horizontal lathes where workpieces are clamped horizontally, the vertical lathe has its main spindle axis arranged vertically, and the worktable is positioned horizontally. This arrangement makes it more convenient for clamping and aligning workpieces. Furthermore, this setup reduces the load on the spindle and bearings, enabling the vertical lathe to maintain its accuracy over long periods of operation.



Machine parameter

Model CK518 CK5112Q CK5112A CK5116Q CK5120A CK5126A
Max. turning diameter of vertical tool rest (mm) 800 1200 1200 1600 2000 2600
Working table diameter (mm) 700 1000 1000 1400 1800 2200
Max. height of work-piece (mm) 800 1000 1000 1200 1250 1400
Max. weight of work-piece (kg) 1500 1500 3200 3200 8000 8000
Range of worktable rotation speed (rpm) 30-260 20-180 6.3-200 15-160 3.2-100 2.2-70
Feeding series Stepless Stepless Stepless Stepless Stepless Stepless
Range of tool rest feed (mm/min) 0.25-90 0.25-90 0.8-86 0.25-90 0.8-86 0.8-86
Cross beam travel (mm) 500 1000 650 1200 890 1090
Horizontal travel of tool rest (mm) 500 700 700 900 1115 1400
Vertical travel of tool rest (mm) 450 500 650 750 800 800
Size of section of cutter bar (mm) 30*40 30*40 30*40 30*40 30*40 30*40
Main motor power (kw) 11 15 22 15 30 30

CK5112 CNC Vertical Lathe Machine Cnc Vertical Borer Milling And Drilling 0CK5112 CNC Vertical Lathe Machine Cnc Vertical Borer Milling And Drilling 1CK5112 CNC Vertical Lathe Machine Cnc Vertical Borer Milling And Drilling 2
