CW61160B Conventional Heavy Duty Lathe Machine Manual Mechanical Turning

CW61160B Manual Heavy Duty Mechanical Turning Horizontal Lathe Machine

Universal horizontal lathe machine introduction:

1. This machine can use to process castings, steel and small-sized and medium-sized parts of nonferrous.
2. They are also suitable for turning external cylindrical, inner hole and end face. In addition it can do groove broaching, drilling, boring and trepanning.
3. They can also cut metric, inch, module, diametrical pitch threads and various internal and external thread.
4. Top slide not only can work independently to cut short conical surface, but also can longitudinal feed to cut long conical surface.
5. Spindle bearings use domestic famous-brand company products.
6. Headstock takes symmetrical structure to make thermal deformation be even, avoiding the spindle center generates offsets.
7. Headstock adopts oil bath circulating lubrication to reduce thermal deformation.
8. Frond end of the spindle adopts three-supporting structure of two-way angular in touch with the ball bearing to improve its accuracy and enhance its rigidity
9. Gears in headstock and guide way are processed by quenching to ensure accurate transmission and high rigidity.

Machine Specification:

Machine Picture:

CW6163 / CW6263 horizontal universal lathe machine:

Main technical data:

Max.swing diameter over bed: 630mm

Max.swing diameter over gap: 800mm

Max.swing diameter over carriage: 350mm

Max. processing workpiece length: according your request

Max.loading capacity:2ton (bed width: 550mm)

CW6180Q / CW6280Q horizontal universal lathe machine:

Main technical data:

Max.swing diameter over bed: 800mm

Max.swing diameter over gap: 1000mm

Max.swing diameter over carriage: 480mm

Max. processing workpiece length: according your request

Max.loading capacity:2ton (bed width: 550mm)

CW6180B / CW6280B horizontal universal lathe machine:

Main technical data:

Max.swing diameter over bed: 800mm

Max.swing diameter over gap: 1000mm

Max.swing diameter over carriage: 480mm

Max. processing workpiece length: according your request

Max.loading capacity:2.5ton (bed width: 600mm)

CW61125Q / CW62125Q horizontal universal lathe machine:

Main technical data:

Max.swing diameter over bed: 1250mm

Max.swing diameter over gap: 1450mm

Max.swing diameter over carriage: 920mm

Max. processing workpiece length: according your request

Max.loading capacity:2.5ton (bed width: 600mm)

Noted: if the bed width is 755mm, the max.loading capacity is 6ton;

CW61160B horizontal universal roll lathe machine:

Main technical data:

Max.swing diameter over bed: 1600mm

Max.swing diameter over carriage: 1200mm

Max. processing workpiece length: according your request

Max.loading capacity:6ton (bed width: 755mm)

Noted: if the bed width is 1100mm, the max.loading capacity is 16ton;

CW61200 horizontal universal roll lathe machine:

Main technical data:

Max.swing diameter over bed: 2000mm

Max.swing diameter over carriage: 1600mm

Max. processing workpiece length: according your request

Max.loading capacity:16ton (bed width: 1100mm)

C61200 heavy duty horizontal conventional roll lathe machine:

Main technical data:

Max.swing diameter over bed: 2000mm

Max.swing diameter over carriage: 1600mm

Max. processing workpiece length: according your request

Max.loading capacity:32ton (bed width: 1600mm)
