CK6150 CNC Precision Lathes Flat Bed

Product Details

Place of Origin: Henan, China

Brand Name: BAISHUN

Certification: ISO

Model Number: CK6150

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiation

Packaging Details: Export standard wooden case package, or as customers' requirement.

Delivery Time: 45 work days

Payment Terms: T/T, L/C, Western Union

Supply Ability: 80 Set/Sets per Month

Get Best Price
Highlight:

CK6150 CNC Precision Lathes

,

CNC Precision Lathes Flat Bed

,

CK6150

Max. Length Of Workpiece (mm):
3000
Structure:
Flat Bed Lathe
Max. Spindle Speed (r.p.m):
1600 R.p.m
Machining Capacity:
Heavy Duty
Max. Weight Of Workpiece(kg):
300
Spindle Bore(mm):
52
Width Of Bed (mm):
400 Mm
Spindle Motor Power(kW):
7.5
No. Of Spindles:
Single
Max. Turned Length (mm):
2800
Number Of Axes:
2
Travel (X Axis)(mm):
260 Mm
Travel (Z Axis)(mm):
850 Mm
Positioning Accuracy (mm):
±0.015
Repeatability (X/Y/Z) (mm):
±0.006
Dimension(L*W*H):
2550*1550*1700mm
Voltage:
380V
Tool Post Stations:
8, 6, 4
Weight (KG):
2800
Product Name:
Automatic Good Quality CNC Lathe CK6150 CNC Lathe For Sale
Turret Type:
4/6/8 Station Turret
X/Z Rapid Traverse:
4/6m/min
Tail Stock Center Travel:
150mm
Max. Length Of Workpiece (mm):
3000
Structure:
Flat Bed Lathe
Max. Spindle Speed (r.p.m):
1600 R.p.m
Machining Capacity:
Heavy Duty
Max. Weight Of Workpiece(kg):
300
Spindle Bore(mm):
52
Width Of Bed (mm):
400 Mm
Spindle Motor Power(kW):
7.5
No. Of Spindles:
Single
Max. Turned Length (mm):
2800
Number Of Axes:
2
Travel (X Axis)(mm):
260 Mm
Travel (Z Axis)(mm):
850 Mm
Positioning Accuracy (mm):
±0.015
Repeatability (X/Y/Z) (mm):
±0.006
Dimension(L*W*H):
2550*1550*1700mm
Voltage:
380V
Tool Post Stations:
8, 6, 4
Weight (KG):
2800
Product Name:
Automatic Good Quality CNC Lathe CK6150 CNC Lathe For Sale
Turret Type:
4/6/8 Station Turret
X/Z Rapid Traverse:
4/6m/min
Tail Stock Center Travel:
150mm
CK6150 CNC Precision Lathes Flat Bed
Product Description



Automatic Good Quality CNC Lathe CK6150 Flat Bed CNC Lathe Machine Price



The CNC lathe is a machine tool that is used for shaping and turning metal workpieces. It use a variety of cutting tools, such as drills, boring tools, and turning tools, to remove material from the workpiece. The machine is programmed using software that specifies the size and shape of the workpiece, as well as the cutting operations to be performed.



The workpiece is clamped in the spindle of the lathe, which rotates at high speed to create the cutting motion. As the workpiece rotates, the cutting tools move in precise patterns to remove material and shape the workpiece.



The CNC system uses the GSK980TC3 and GSK system servo drive. It also adopts domestically renowned and high-quality ball screws and high-precision screw bearings.



CK6150 CNC Precision Lathes Flat Bed 0CK6150 CNC Precision Lathes Flat Bed 1CK6150 CNC Precision Lathes Flat Bed 2CK6150 CNC Precision Lathes Flat Bed 3CK6150 CNC Precision Lathes Flat Bed 4CK6150 CNC Precision Lathes Flat Bed 5CK6150 CNC Precision Lathes Flat Bed 6CK6150 CNC Precision Lathes Flat Bed 7CK6150 CNC Precision Lathes Flat Bed 8CK6150 CNC Precision Lathes Flat Bed 9CK6150 CNC Precision Lathes Flat Bed 10



Machine Parameter



Specifications

CK6140

CK6150

CK6161

CK6166

CK6180

Max. swing over bed

400mm

500mm

610mm

660mm

800mm

Max. workpiece length

750/1000/1500/2000/3000mm

Spindle taper

Mohs NO.6(MT6)[ Φ90 1:20(Type B)][ Φ113 1:20(Type C)]

Chuck size

C6[D8(Type B/C)]

Spindle bore dia.

Φ52mm/[Φ80mm(Type B)][Φ105mm(Type C)]

Range of spindle speeds 3 steps(Auto. Change gear)

Independent spindle:100~1600r/min
21-1500r/min(Ⅰ62-1500 Ⅱ66-500 Ⅲ21-150)

Tail stock center travel

150mm

Tail stock sleeve taper

MT5

Positioning accuracy

±0.015mm

Repositioning accuracy

±0.006mm

X/Z rapid traverse

4/6m/min

Spindle motor

7.5kw

11kw

Overall dimensions for750

2550*1550*1700mm

2550*1550*1900mm

Overall dimensions for1000

2750*1550*1700mm

2750*1550*1900mm

Overall dimensions for1500

3250*1550*1700mm

3250*1550*1900mm

Overall dimensions for2000

3700*1550*1700mm

3700*1550*1900mm

Overall dimensions for3000

4710*1550*1700mm

4710*1550*1900mm

G.W for750(kg)

2800

2900

2850

2900

3000

G.W for1000(kg)

2900

3000

3000

3050

3150

G.W for1500(kg)

3150

3200

3200

3250

3350

G.W for2000(kg)

3350

3400

3400

3450

3550

G.W for3000(kg)

4100

4200

4250

4300

4400
