CK6161X1000mm Flat Bed CNC Lathe Machine High Precision Tools

Name: CK6161X1000mm Flat Bed CNC Lathe Machine High Precision Tools
Brand: Henan Baishun Machinery Equipment Co., Ltd.
SKU: CK6161X1000mm
Price: 14,500.00 USD
Availability: InStock

Product Details

Place of Origin: Henan, China

Brand Name: BAISHUN

Certification: ISO

Model Number: CK6161X1000mm

Document: Product Brochure PDF

Payment & Shipping Terms

Minimum Order Quantity: 1 set

Price: Negotiation

Packaging Details: Export standard wooden case package or Negotiation with customers

Delivery Time: 45 work days

Payment Terms: T/T, L/C, Western Union

Supply Ability: 40 Set/Sets per month

Get Best Price

Product Details

Product Description

Highlight:
                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                                CNC Lathe High Precision Machine, CK6161 Flat Bed CNC Lathe Machine, CNC Lathe Flat Bed


Type:	Horizontal	Max. Length Of Workpiece (mm):	3000
Max. Spindle Speed (r.p.m):	1500 R.p.m	Machining Capacity:	Light Duty
Spindle Bore(mm):	100	Width Of Bed (mm):	550 Mm
Spindle Motor Power(kW):	11	No. Of Spindles:	Single
Number Of Axes:	2	Travel (X Axis)(mm):	610 Mm
Travel (Z Axis)(mm):	750 Mm	Positioning Accuracy (mm):	0.03
Repeatability (X/Y/Z) (mm):	0.012	Dimension(LWH):	255015501900mm
Voltage:	380V/50Hz	Tool Post Stations:	6, 4
Weight (KG):	5000	Name:	Factory Price CNC Lathe High Quality Machine Tools CNC Lathe Machine
Max. Swing Over Bed:	610mm	Tail Stock Center Travel:	150mm
X/Z Rapid Traverse:	4/6m/min	Distance Between Centres:	3000mm
Motor Power:	7.5KW

Type:	Horizontal
Max. Length Of Workpiece (mm):	3000
Max. Spindle Speed (r.p.m):	1500 R.p.m
Machining Capacity:	Light Duty
Spindle Bore(mm):	100
Width Of Bed (mm):	550 Mm
Spindle Motor Power(kW):	11
No. Of Spindles:	Single
Number Of Axes:	2
Travel (X Axis)(mm):	610 Mm
Travel (Z Axis)(mm):	750 Mm
Positioning Accuracy (mm):	0.03
Repeatability (X/Y/Z) (mm):	0.012
Dimension(LWH):	255015501900mm
Voltage:	380V/50Hz
Tool Post Stations:	6, 4
Weight (KG):	5000
Name:	Factory Price CNC Lathe High Quality Machine Tools CNC Lathe Machine
Max. Swing Over Bed:	610mm
Tail Stock Center Travel:	150mm
X/Z Rapid Traverse:	4/6m/min
Distance Between Centres:	3000mm
Motor Power:	7.5KW

CK6161X1000mm Flat Bed CNC Lathe Machine High Precision Tools

Factory Price CNC Lathe High Precision Machine Tools Flat Bed CNC Lathe Machine

Product Description

Horizontal CNC lathe machine

Features:
(1)The machine can process precisely internal or external diameter, face, taper, arc and threading with high efficiency.
(2) Standard tool-post is 4-stations, also 6-stations tool-post can be optional selection Spindle speed changed by frequency.
(3)Induction harden bedway. Bed saddle with plastic sticker can improve the accuracy and service life of the machine.
(4)The spindle is supported by imported precision bearings.
(5)Normally machine is provided with 3jaw chuck. According to customer’s optional selection, hydraulic chuck or pneumatic chuck also can be supplied.

CK6161X1000mm Flat Bed CNC Lathe Machine High Precision Tools 0

CK6161X1000mm Flat Bed CNC Lathe Machine High Precision Tools 1

Elenctric 4-position turret:

CK6161X1000mm Flat Bed CNC Lathe Machine High Precision Tools 9

With Tail stock:

CK6161X1000mm Flat Bed CNC Lathe Machine High Precision Tools 10

Machine parameter

Specifications	CK6140	CK6150	CK6161	CK6166	CK6180
Max. swing over bed	400mm	500mm	610mm	660mm	800mm
Max. workpiece length	750/1000/1500/2000/3000mm
Spindle taper	Mohs NO.6(MT6)[ Φ90 1:20(Type B)][ Φ113 1:20(Type C)]
Chuck size	C6[D8(Type B/C)]
Spindle bore dia.	Φ52mm/[Φ80mm(Type B)][Φ105mm(Type C)]
Range of spindle speeds 3 steps(Auto. Change gear)	Independent spindle:100~1600r/min 21-1500r/min(Ⅰ62-1500 Ⅱ66-500 Ⅲ21-150)
Tail stock center travel	150mm
Tail stock sleeve taper	MT5
Positioning accuracy	±0.015mm
Repositioning accuracy	±0.006mm
X/Z rapid traverse	4/6m/min
Spindle motor	7.5kw			11kw
Overall dimensions for750	255015501700		255015501900
Overall dimensions for1000	275015501700		275015501900
Overall dimensions for1500	325015501700		325015501900
Overall dimensions for2000	370015501700		370015501900
Overall dimensions for3000	471015501700		471015501900
